Chain Actuator WAY Mingardi Micro S 24V Stroke 200-250mm 200N
Chain actuator for: top hinged windows, bottom hinged windows, roof windows.
MINGARDI linear electric actuator with reinforced double-sprocket chain inside the actuator body.
Operating voltage: 24V DC in conformity with Directive 2004/108 EMC.
Outfitted with electronic limit switch system for opening and closing, which can be connected in parallel.
Colours available: anodised silver (A) - anodised black (N) - RAL 9016 (B).
Characteristics:
- Very reduced dimensions;
- Double-link chain;
- Low consumption;
- Maintenance free;
- Protection degree IP 20;
- Limit switch closing-opening: Electronic-Absorption.
Colour: Anodised silver (A) - Anodised black (N) - RAL 9016 (B).
Universal kit for fitting top-hinged windows (code: 2700093) sold separately.
Universal kit for fitting bottom-hinged windows (code: 2700094) sold separately.
Universal kit for fitting roof windows (code: 2700096) sold separately.
Pivoting bracket for horizontal plane applications (code: 2700080) sold separately.
Technical Features*
| Description |
Voltage |
Thrust Tensile |
Stroke |
Power Consumption |
Speed Min. |
| Micro S |
24V |
200 N |
200 mm
250 mm
(your choice) |
20 W |
ca. 10 mm/s |
THE VALUES INDICATED ON THE TABLE WERE RECORDED IN A CLIMATIC TEST CHAMBER AT OPERATING TEMPERATURES BETWEEN -10°C/+40°C WITH MAX 60% RELATIVE HUMIDITY.
