Holding Electromagnet 55 Kg for Swing or Sliding Fire Doors - 01630 Opera - Without Counterplate
Holding electromagnet for swing or sliding fire doors with counterweights.
- By choice
- Standard : as description below
- Force reduced to 20 Kg : prevents the magnet from detaching from the wall after repeated misuse
Technical characteristics Holding electromagnet 55 Kg
- Electromagnet body with fixing base
- Nickel plated electromagnet block
- Fixing base dimensions: mm. 65x65x3
- Electromagnet dimensions: diameter mm. 50 x height mm. 40
- Power supply: 24 Vdc - Absorbed current: 70 mA
- Traction force: > 55 Kg.
- Residual anti-magnetism spring on the electromagnet body
On request
Contact us to add variants:
- 12 Vdc power supply
- 12 Vac power supply
- 24 Vac power supply
- Lifetime connector
- Status sensor
IMPORTANT
Supplied without counterplate.
The counterplate can be purchased on our website. Choose between:
- Fixed Counterplate (Art. 01800Z Opera)
- Articulated counterplate (Art. 01805Z Opera).
Fire Control Series Opera
- Holding electromagnets for fire doors
- Regulators for sliding fire doors
- Hydraulic shock absorbers
- Single-zone fire alarm control panels
- Smoke and heat detectors
