Slide 200 24Vdc Chiaroscuro - Motor for Sliding Shutters - Max 300Kg
Motor for sliding shutters Slide 200 24Vdc Chiaroscuro with 24 Vdc power supply - Max total weight 300 Kg - Force 200 N.
Slide 200 24Vdc Chiaroscuro Sliding Shutter Motor Kit: what does it include?
- Motor with rail plate with internal groove max 15mm - Pieces: 1;
- Belt T5H10 - Meters: 10;
- Straight dragging bracket - Pieces: 2;
- Tensioner with idle transmission pinion - Pieces: 1;
- Use and maintenance manual.
Slide 200 24Vdc Chiaroscuro is robust and reliable
The automatic solution for moving heavy shutters.
So many reasons to choose this sliding shutter motor
Convenient: with a simple click you can close and open your doors.
Safe: thanks to the 24 Vdc and irreversible motor.
External control unit: self-learning, automatic movement control unit that can be fully integrated with all home automation systems; meets the safety requirements in the event of an impact and allows movement with partial crash scenarios.
Optional: the power supply to operate the motor at 230V can be purchased separately on Windowo.
| Template |
Slides 200 |
| Motor power supply |
24 Vdc |
| Max total weight |
300 Kgs |
| light max |
250cms |
| Speed |
10cm/s |
| Engine power |
60W |
| Average absorption |
1 A |
| Force |
200 No |
| Working cycle |
10 cycles/hour |
| Noisiness |
42dB |
| Degree of protection |
IP32 |
| Frequency |
433MHz |
| Irreversible |
Yup |
| Electric lock |
Yup |
